IEC 62930 Tinned Copper PV Cable

SOWELLSOLAR is the Chinese manufacturer of solar cable. IEC 62930 Tinned Copper PV Cable is tested and certified for usage in fixed underground installation for PV systems as per the international standard by IEC.

Send Inquiry

Product Description

SOWELLSOLAR specializes in photovoltaic cables, tinned copper PV cable, tinned alloy PV cable, aluminum alloy and PV grounding cable. IEC 62930 Tinned Copper PV Cable is one of those types, approved by IEC. SOWELLSOLAR is the professional supplier in photovoltaic industry in China. Our products have high conductivity, good durability, strong current load capability. Rated voltage is 1500V, regular model is from 2.5 squire millimeter to 35 squire millimeters, customized model also is acceptable. The common color is red and black. Our popular is 4mm2, 6mm2, 10mm2, different specifications can meet different needs of your company. And MOQ is not large and delivery time is fast.

IEC 62930 Tinned Copper PV Cable Specification

Part No	Conductor cross section mm²	Strand design Number x φmm	Conductor resistance Ω/km 20℃	Outer-φmm	Sheath Color
PV-H1-15B	1X1.5	30/0.25	13.70	4.7±0.1mm	Black
PV-H1-15R	1X1.5	30/0.25	13.70	4.7±0.1mm	Red
PV-H1-25B	1X2.5	49/0.25	8.21	5.3±0.1mm	Black
PV-H1-25R	1X2.5	49/0.25	8.21	5.3±0.1mm	Red
PV-H1-40B	1X4,0	56/0.282	5.09	5.6±0.1mm	Black
PV-H1-40R	1X4,0	56/0.282	5.09	5.6±0.1mm	Red
PV-H1-60B	1X6,0	84/0.282	3.39	6.1±0.1mm	Black
PV-H1-60R	1X6,0	84/0.282	3.39	6.1±0.1mm	Red
PV-H1-100B	1X10	77/0.4	1.95	7.3±0.1mm	Black
PV-H1-100R	1X10	77/0.4	1.95	7.3±0.1mm	Red

IEC 62930 Tinned Copper PV Cable is our qualified product. PV cable is used in solar power system, to connect solar panels and inverters. It can be used in outdoor, the working temperature is from -40℃ to 90℃. Tinned Copper PV Cable is a reliable and efficient choice for all. IEC 62930 is a standard of tinned copper photovoltaic cables. The standard is formulated by International Electrotechnical Commission. It’s best industry authority. IEC sets requirements for the conductor, material, voltage rating, insulation and others. And we are honor to get this certificate.

Established in 2006, SOWELLSOLAR maintains 2 manufacturing facilities in China roughly covering a production area of 50,616 square meters and employs 11 cable extrusion production lines with a capacity to produce more than 300 thousand meters of tinned copper cable per day.

Mass production can reduce the cost of products, but it is impossible to sell at a price lower than the cost of raw materials. As an important power output channel, excellent product quality is more important. We look forward to establishing long-term friendly relations with cooperators who focus on product quality.
